- 100mm Ball
- Payload Boost Button
- Sideload Quick Release & Camera Plate
- 22 kg Maximum Payload Capacity
- 16 Step Counterbalance
Email me when stock arrives
- Product: #40645
- SKU: ST-1910-NZ
The Sachtler Cine 7+7 HD 1910 is a fluid head for film and video camcorders that features a 100mm ball for fast levelling without having to adjust the legs, and supports up to 22 kg. This head provides two support ranges, 2 to 14.9 kg for shooting with small and compact sized cameras, and 9.1 to 22 kg for shooting with a medium sized cameras. The payload range is selected by using the payload boost button. The fluid head features 5.9"(150 mm) of balance adjustment with the sliding balance plate, and it incorporates a sideload QR mechanism.
The head also features independent horizontal and vertical drag adjustment, with each axis having seven levels of drag, plus a zero setting for no drag. The fluid head also provides 16 counterbalance settings. The counterbalance and drag settings are stepped and not variable, which makes them accurate and repeateable. The built-in illuminated bubble level confirms that your fluid head is level, and features a replaceable battery.
The sideload clamping system combines the features of a quick release plate and a sliding balance plate. This makes it easier to mount and dismount the camera from the tripod than with just a sliding baseplate system, while still being able to balance the camera on the head using the 150 mm of adjustment the sliding baseplate allows.
A 16-Step counterbalance ensures accurate and fast balancing of many camera systems 2 to 22 kg.
There is a payload high and low adjustment called the boost button. This boost will offer a top heavy system a little extra control on radical pans and tilts.
This head offers very specific levels of 7 horizontal and 7 vertical drag for silky smooth pans and tilts.
Low: 2 to 14.9 kg
High: 9.1 to 22 kg
|Fitting Size & Type||100 mm Ball|
|Counter Balance System||16 Step|
|Sliding Balance Plate Travel||5.9"
|Quick Release/Wedge Plate||Sideload Plate M|
|Tilt Drag||7 Steps plus 0 setting|
|Tilt Range||+90 to -80°|
|Pan Drag||7 Steps plus 0 setting|
|Temperature Range||-40° to +60° C|
