Sachtler 1910 Cine 7+7 HD Fluid Head
Product #40645 | SKU ST-1910-NZ
Usually ships in 3 - 4 weeks
0.0 (no ratings yet) Thanks for your rating!

Sachtler 1910 Cine 7+7 HD Fluid Head

Product #40645 | SKU ST-1910-NZ
Usually ships in 3 - 4 weeks

Product Features
  • 100mm Ball
  • Payload Boost Button
  • Sideload Quick Release & Camera Plate
  • 22 kg Maximum Payload Capacity
  • 16 Step Counterbalance
Customer Reviews
0.0 (no ratings yet) Thanks for your rating!
Email me when stock arrives
Product Details
  • Product: #40645
  • SKU: ST-1910-NZ
Our Price $12,849.00
- +
or apply for 12 months interest free with

Delivery - $9.90*
3 - 4 weeks
3 - 4 weeks
3 - 4 weeks
*estimated shipping to Auckland


The Sachtler Cine 7+7 HD 1910 is a fluid head for film and video camcorders that features a 100mm ball for fast levelling without having to adjust the legs, and supports up to 22 kg. This head provides two support ranges, 2 to 14.9 kg for shooting with small and compact sized cameras, and 9.1 to 22 kg for shooting with a medium sized cameras. The payload range is selected by using the payload boost button. The fluid head features 5.9"(150 mm) of balance adjustment with the sliding balance plate, and it incorporates a sideload QR mechanism.

The head also features independent horizontal and vertical drag adjustment, with each axis having seven levels of drag, plus a zero setting for no drag. The fluid head also provides 16 counterbalance settings. The counterbalance and drag settings are stepped and not variable, which makes them accurate and repeateable. The built-in illuminated bubble level confirms that your fluid head is level, and features a replaceable battery.

Key Features

Sideload Clamp
The sideload clamping system combines the features of a quick release plate and a sliding balance plate. This makes it easier to mount and dismount the camera from the tripod than with just a sliding baseplate system, while still being able to balance the camera on the head using the 150 mm of adjustment the sliding baseplate allows.

A 16-Step counterbalance ensures accurate and fast balancing of many camera systems 2 to 22 kg.

Boost Button
There is a payload high and low adjustment called the boost button. This boost will offer a top heavy system a little extra control on radical pans and tilts.

This head offers very specific levels of 7 horizontal and 7 vertical drag for silky smooth pans and tilts.


Load Capacity Range
Low: 2 to 14.9 kg
High: 9.1 to 22 kg
Fitting Size & Type 100 mm Ball
Counter Balance System 16 Step
Sliding Balance Plate Travel 5.9"
Quick Release/Wedge Plate Sideload Plate M
Tilt Drag 7 Steps plus 0 setting
Tilt Range +90 to -80°
Tilt Lock Yes
Pan Drag 7 Steps plus 0 setting
Pan Range 360°
Pan Lock Yes
Levelling Bubble/Illuminated Yes/Yes
Temperature Range -40° to +60° C
Weight 3.3kg

In The Box

  • Sachtler 1910 Cine 7+7 HD Fluid Head
  • 1164 Sideload Plate M
  • Pan Bar
  • CR 2032 Battery
  • Limited 1-Year Warranty, Extendable to 2-Years with Product Registration
