Satechi Thunderbolt 4 Multimedia Pro Dock has been discontinued, here are some related products you might like:

Satechi Thunderbolt 4 Multimedia Pro Dock

Product #111894 | SKU ST-DT4PMM-AU | Satechi
This product is no longer available what does this mean?
Not currently for sale
Contact us for more information
This product is no longer available what does this mean?

Features

  • Thunderbolt 4 Host Connection
  • 1 x USB-C 3.2 Gen 2 Port
  • 3 x USB-A 3.2 Gen 2 Ports
  • 2 x USB-A 3.2 Gen 1 Ports
  • 1 x USB-A 2.0 for Charging up to 7.5W
  • 2 x DisplayPort & 2 x HDMI 2.1 Ports

Description

This versatile Satechi Thunderbolt 4 Multimedia Pro Dock is designed for content creators, offering a range of features to enhance your Windows or Mac setup. With support for up to four additional displays, Gigabit Ethernet, and 96W of pass-through charging, this dock is a powerful addition to your workflow. Simply plug in the DC power cord and connect the provided Thunderbolt 4 cable to your host device to get started.

When it comes to external displays, Windows Devices have the capability to support up to four screens using the DisplayPort and HDMI 2.1 ports. These ports can output a 4K resolution at 60 Hz for three of the screens, while the fourth screen can achieve a 4K resolution at 30 Hz. On the other hand, Apple's M1 Pro/Max and M2 Pro/Max MacBook Pro models can connect two external displays with a 4K resolution at 60 Hz. Meanwhile, Apple's M1 and M2 MacBook Pro/Air, as well as Apple's M1, M2, and M2 Pro Mac Mini, can connect a single external display at 4K resolution and 60 Hz.

Specifications

Key Specs
USB 1 x USB-C (Thunderbolt 4) / Supports 96 W Power Delivery
1 x USB-C 3.1/3.2 Gen 2
3 x USB-A 3.1/3.2 Gen 2
2 x USB-A 3.0 / 3.1/3.2 Gen 1
1 x USB-A 2.0 / Supports 7.5 W Output
Ethernet 1 x RJ45 (2.5 Gb/s)
Display 2 x DisplayPort 1.4
2 x HDMI 2.1 (Female)
Audio 1 x 1/8" / 3.5 mm Headphone/Microphone Combo Jack
Media Card Reader 1x SD (Unspecified Type)
1x microSD (Unspecified Type)
System Connection USB-C (Thunderbolt 4)
Ports
USB 1 x USB-C (Thunderbolt 4) / Supports 96 W Power Delivery
1 x USB-C 3.1/3.2 Gen 2
3 x USB-A 3.1/3.2 Gen 2
2 x USB-A 3.0 / 3.1/3.2 Gen 1
1 x USB-A 2.0 / Supports 7.5 W Output
Ethernet 1 x RJ45 (2.5 Gb/s)
Display 2 x DisplayPort 1.4
2 x HDMI 2.1 (Female)
Audio 1 x 1/8" / 3.5 mm Headphone/Microphone Combo Jack
Media Card Reader 1x SD (Unspecified Type)
1x microSD (Unspecified Type)
Host Connections
System Connection USB-C (Thunderbolt 4)
Connection Type Detachable Cable
Powered Connection 135 W
General
Number of Displays Supported 4
Maximum Resolution Supported 3840 x 2160 at 60 Hz (Quad Display)
UASP Support No
Power
Power Source AC Adapter
Power I/O Barrel Connector (Unspecified Diameter) (Input)
Maximum Power Consumption 135 W
DC Input Power 20 VDC
Physical
Cable Length 32" / 81.3 cm
Colour Gray
LED Indicator Power
Enclosure Material Aluminium
Lock Slot Yes, Kensington
Dimensions 7.7 x 4.1 x 1.9" / 195 x 105 x 47 mm
Weight 24.4 oz / 693 g

In The Box

  • Satechi Thunderbolt 4 Multimedia Pro Dock
  • USB-C Thunderbolt 4 Cable
  • AC Adapter
  • Vertical Stand
