Sennheiser SKP 100 G4 Plug-On Transmitter for Dynamic Microphones (B: 626 - 668 MHz)
Usually ships in 4 - 6 weeks
Our Price
$469.00
Usually ships in 4 - 6 weeks
Email me when stock arrives
Shipping & Availability
Usually ships in 4 - 6 weeks.
Deliver to
Auckland
for $8.90
Change location
Click & Collect Availability
Wellington
Out of stock.
Pickup in
4 - 6 weeks
Click & Collect
Features
- B Band (626 to 668 MHz)
- 1680 Tunable Frequencies Across 42 MHz
- Pilot Tone Squelch
- 20 Banks with 12 Channel Presets Each
- Compander for Clearer Sound
Description
The SKP 100 G4 Plug-On Transmitter for Dynamic Microphones from Sennheiser is the latest addition to their evolution family of wireless microphones and is fully compatible with all previous series. Featuring an updated high-contrast LCD display, blue sync LED, and a dedicated escape button, it can be used when paired with a dynamic microphone and portable receiver (sold separately) for capturing audio in live sound, broadcast, film, business, and educational applications.
It easily plugs onto microphones with XLR connections transforming them into world-class wireless units when combined with EM 100 G4 or EK 100 G4 receivers. This compact and lightweight transmitter has a run-time of up to 8 hours on just (2) AA batteries.
Features
- The evolution Wireless G4 retains all of G3's best features
- Quicker setup
- High-contrast LCD display
- Blue sync LED
- Dedicated escape button
- Sturdy metal housing
- 42 MHz bandwidth: 1680 tunable UHF frequencies for interference-free reception
- Enhanced frequency bank system with up to 12 compatible frequencies
- Pilot tone squelch for eliminating RF interference when transmitter is turned off
- Enhanced AF frequency range
- Wireless synchronisation of transmitter via infrared interface
- User-friendly menu operation with more control options
- Auto-Lock function avoids accidental changing of settings
- HDX compander for crystal-clear sound
- Operates on 2 standard AA batteries
- Transmitter features battery indication in 4 steps
- Contacts for recharging BA 2015 accupack directly in the transmitter
- Wide range of accessories adapts the system to any requirement
Specifications
| Modulation | Wideband FM |
| Frequency Band | B: 626 - 668 MHz |
| Receiving Frequency | Maximum 1680 receiving frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels |
| Switching Bandwidth | Up to 42 MHz |
| Nominal/Peak Deviation | ±24 kHz / ±48 kHz |
| Frequency Stability | ≤ ±15 ppm |
| RF Output Power | @ 50 Ohms: Maximum 30 mW |
| Pilot Tone Squelch | Can be switched off |
| Compander | Sennheiser HDX |
| AF Frequency Response | 80 Hz to 18 kHz |
| Signal to Noise Ratio | ≥ 110 dBA (1 mV, peak deviation) |
| Total Harmonic Distortion (THD) | ≤ 0.9% |
| Maximum Input Voltage | 3.3 V eff |
| Input Impedance | 68 kOhms, unbalanced |
| Input Capacitance | Switchable |
| Input Sensitivity Range | 48 dB, adjustable in 6 dB steps |
| Temperature Range | 14 to 131°F / -10 to 55°C |
| Power Supply | 2 x AA 1.5 V batteries, or BA 2015 accupack |
| Nominal Voltage | 3 V battery / 2.4 V rechargeable battery |
| Current Consumption | Nominal Voltage: Typical 180 mA With Transmitter Switched Off: ≤ 25 μA |
| Dimensions (W x L x H) | 105 x 43 x 43 mm |
| Weight | 195 g (including batteries) |
In The Box
- Sennheiser SKP 100 G4 Plug-On Transmitter for Dynamic Microphones (B: 626 - 668 MHz)
- 2 x AA Battery
