Shure SLXD2/SM58 Digital Wireless Handheld Microphone Transmitter with SM58 Capsule
this item may be nonreturnable
Features
- For SLX-D Receivers
- SM58 Cardioid Dynamic Mic Capsule
- Interchangeable Mic Capsule System
- 1760 Auto-Scan Frequencies
- 1/10mW RF Output Power
Related Products
Description
The Shure Shure SLXD2/SM58 Digital Wireless Handheld Microphone Transmitter with SM58 Capsule is a digital handheld wireless microphone transmitter compatible with SLX-D receivers. It comes equipped with the legendary SM58 dynamic capsule, an industry standard for vocal performers and presenters. The capsule features a cardioid polar pattern that minimises background noise and feedback, and its brightened midrange and bass roll-off gives you that sought-after warm and clear vocal reproduction.
The system operates on a 44 MHz UHF tuning range with 1760 frequencies available. The transmitter features a selectable 1/10mW RF power output and a transmission range up to 100m. It provides up to 8 hours of operation on two AA batteries or a rechargeable SB903 battery pack (available separately).
The SLXD2/SM58 handheld transmitter delivers crystal-clear, 24-bit digital audio quality and reliable RF performance in a lightweight, yet durable aluminium housing. It is well suited for use in small- to medium-sized venues and houses of worship and with A/V installations in a conference, educational, or corporate facilities.
Key Features:
Clear, Accurate Audio with Interchangeable Capsule
- The unit delivers clear, reliable 24-bit digital audio.
- The interchangeable capsule design allows you to replace the SM58 capsule with a Shure capsule that’s ideal for your application and simply screw it onto the transmitter—including the Beta 87A, KSM8, and Beta 58A capsules.
User-Friendly Features in a Rugged Housing
- The unit quickly syncs with a wireless receiver via infrared at the touch of a button.
- An easy-to-read LCD shows important information.
- 1/10mW selectable RF output power allows you to increase either the transmitter's range or the number of mics operating simultaneously.
Convenient Power Management Options
- The transmitter runs for up to 8 hours on two AA batteries.or an SB903 rechargeable battery (available separately).
- The SB903 lithium-ion rechargeable battery offers convenient power management with zero memory effect and precision metering in hours and minutes on the transmitter's LCD screen.
- The SBC203 dual-battery recharging station (available separately) charges two SB903 batteries at once—it fits the external contacts on the transmitter so you don't have to remove the batteries to recharge.
Specifications
System | |
Wireless Transmission | Digital UHF |
RF Channel Scanning | Auto-Scan |
Max Operating Range | 328' / 100 m |
Max Systems per Setup | 32 |
Sample Rate/Resolution | 24-Bit |
Latency | 3.2 ms |
Encryption | None |
Transmitter | |
Form Factor | Handheld |
RF Output Power | 1 / 10 mW |
Audio I/O | None |
Pad | None |
Muting | None |
Audio Input Level | 8.2 dBV |
Auto-Level Control | No |
Gain Range | 0 +21 dB |
Signal Processing | None |
Frequency Response | 20 Hz to 20 kHz (Dependant on Mic) |
Sync Method | IR |
Antenna | Internal Single-Band Helical |
Power Requirements | Battery |
Battery Type | 2 x AA (Included) 1 x Shure SB 903 (Not Included) |
Battery Charging Time | 1.25 to 5.5 Hours |
Approx. Battery Life | 8 Hours (Lithium Shure SB903) 8 Hours (Alkaline) |
USB/Lightning Connectivity | None |
Display & Indicators | LCD (Battery Status, Channel, Group, Power) |
Housing | Aluminium |
Operating Temperature | 0 to 122°F / -17 to 50°C |
Storage Temperature | -20 to 165°F / -28 to 73°C |
Dimensions | 1.5 x 6.9" / 37.1 x 176 mm |
Weight | 5.2 oz / 147 g |
Microphone | |
Form Factor | Handheld Capsule |
Sound Field | Mono |
Capsule | Dynamic |
Polar Pattern | Cardioid |
Frequency Range | 50 Hz to 15 kHz |
Sensitivity | -54.5 dBV/Pa |
CMRR | None |
Diameter | 1.97" / 50 mm |
General |
In The Box
- Shure SLXD2/SM58 Digital Wireless Handheld Microphone Transmitter with SM58 Capsule
- Wireless Microphone Clip
- AA Batteries
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Shure SLXD2/SM58 Digital Wireless Handheld Microphone Transmitter with SM58 Capsule
- Manufacturer: Shure
- Model: SLXD2-SM58
- SKU: SLXD2-SM58
- RM Product #: 75962
- Warranty: 2 year manufacturer warranty (excluding consumable e.g. lithium-ion batteries).
