StarTech Conference Table Connectivity Box for AV

Product #84819 | SKU BOX4HDECP2 | Startech
Contact us for an ETA what does this mean?
Our Price $799.00
Contact us for an ETA what does this mean?
This product can't be purchased at this time, please contact us for more information.
- +

Email me when stock arrives


Features

  • Collaborate Easily Using the Big Screen
  • Easily collaborate
  • Charge your phone or tablet
  • Three accessible USB charge ports
  • Provide secure, wired network connectivity

Related Products

Logitech Rally Plus Ultra-HD ConferenceCam System Logitech Rally Plus Ultra-HD ConferenceCam System
Logitech Rally Ultra-HD ConferenceCam System Logitech Rally Ultra-HD ConferenceCam System
Logitech ConferenceCam Connect Portable (Silver) Logitech ConferenceCam Connect Portable (Silver)

Description

This StarTech Conference Table Connectivity Box for AV installs in your table or lectern to provide A/V, networking, and USB charging connectivity in your boardroom, auditorium, or classroom. The box makes it easy to connect HDMI, DisplayPort and VGA laptops to your room’s large HDMI display, and provides LAN and USB power connectivity for charging USB devices. The box also provides some boardroom cable management by hiding connectivity cables in your table.

Key Features:

Collaborate Easily Using the Big Screen

The table box enables presenters in your conference room to easily share their laptop screen on the room’s large display or projector, with supported resolutions up to 4K 30Hz.

To share video from virtually any laptop, the table box supports HDMI, VGA and DisplayPort inputs and automatically outputs the most recently connected input to the HDMI display.

Provide Convenient USB Charging and Wired Network Connectivity

Enabling visitors in your conference room to charge their iPhone, iPad, smartphone, or tablet, the table box features three USB charge ports. Plus, the box features an Ethernet pass-through port to provide secure wired network connectivity in rooms where Wi-Fi® isn’t available.

Add Style and Technological Sophistication to Any Room

The boardroom interconnect box has an aluminum finish that complements your space. The hideaway panel eliminates clutter by discreetly covering the connection ports when they’re not in use.

Specifications

Connector(s)
1 - Connector A HDMI (19 pin)
1 - Connector B HDMI (19 pin)
1 - Connector A VGA (15 pin, High Density D-Sub)
3.5 mm Mini-Jack (3 Position)
1 - Connector B RJ-45
1 - Connector A RJ-45
3 - Connector A USB Type-A (4 pin) USB 2.0
1 - Connector A DisplayPort (20 pin)
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 10% to 85% (non-condensing)
Hardware
Active or Passive Adapter Active
AV Input VGA
3.5 mm Audio
Active or Passive Adapter Passive
AV Output HDMI
AV Input HDMI
DisplayPort
Audio Yes
USB Pass-Through No
Packaging Information
Shipping (Package) Weight 4.0 lb [1.8 kg]
Package Length 6.7 in [17.0 cm]
Package Width 3.9 in [100.0 mm]
Package Height 3.9 in [98.0 mm]
Performance
Video Revision HDMI 1.4
DisplayPort 1.2
Maximum Cable Length 50.0 ft [15.2 m]
Maximum Analog Resolutions 1920 x 1200 60Hz
Maximum Digital Resolutions 3840x2160 (4K) 30Hz
Supported Resolutions 3840x2160 (4K) 30Hz (HDMI and DP Inputs Only)
2560x1600 60Hz (HDMI and DP Inputs Only)
1920x1200 60Hz (Maximum VGA Input)
1920x1080 (1080p) 60Hz
1280x720 (720p) 60Hz
**Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Aspect Ratio 16:09
Wide Screen Supported Yes
Physical Characteristics
Weight of Product 3.8 lb [1.7 kg]
Color Silver
Product Length 6.7 in [17.0 cm]
Product Width 3.9 in [100.0 mm]
Product Height 3.9 in [98.0 mm]
Power
Power Source AC Adapter Included
Input Voltage 100 - 240 AC
Output Voltage 12V DC
Output Current 2A
Plug Type N
Power Consumption (In Watts) 24

In The Box

  • Conference table box
  • Universal power adapter (NA/JP, EU, UK, ANZ)
  • Die cut outline
  • 2 x mounting brackets
  • Cable tie bracket
  • 2 x cable tie bracket screws
  • Quick-start guide

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: StarTech Conference Table Connectivity Box for AV
  • Manufacturer: Startech
  • Model: BOX4HDECP2
  • SKU: BOX4HDECP2
  • RM Product #: 84819
