| Computing |
|
| CPU |
2.6 to 3.1 GHz Dual-Core |
| Processor |
AMD Ryzen R1600 |
| Total Installed Memory |
4 GB ECC DDR4 |
| User-Replaceable Memory |
1 x 4 GB |
| Total Memory Slots |
2 x SO-DIMM |
| Maximum Memory Capacity |
32 GB |
| General |
|
| Number of Bays |
4 x 2.5"/3.5"
2 x M.2 (2280) |
| Inputs/Outputs |
2 x RJ45 Gigabit Ethernet
2 x USB-A 3.0 / 3.1/3.2 Gen 1
1 x eSATA |
| Compatible Drive Interface |
SATA III, NVMe |
| Media Card Slots |
None |
| Form Factor |
Desktop |
| RAID |
RAID 0, 1, 10, 5, 6, JBOD, Synology Hybrid |
| Hot-Swap Support |
Yes |
| PCI Expansion |
1 x PCIe 3.0 x2 |
| Wake on LAN |
Yes |
| Link Aggregation and Failover Support |
Yes |
| Networking |
|
| Supported Protocols |
AFP
CalDAV
FTP
HTTPS
L2TP
NFS
OpenVPN
PPTP
Rsync
SFTP
SMB
SNMP
SSH
SSL
TFTP
Telnet
WebDAV
iSCSI |
| iSCSI LUN |
256 |
| iSCSI Target |
128 |
| Max Concurrent Connections |
1000 |
| Max Folders |
512 |
| Max Sync Tasks |
32 |
| Max Groups |
256 |
| Max User Accounts |
2048 |
| Max Volume Number |
64 |
| Max Cameras Supported |
40 |
| Software |
|
| Installed Operating System |
Synology DSM |
| Supported File Systems |
Internal: BTRFS, EXT4
External: BTRFS, EXT3, EXT4, FAT32, HFS+, NTFS, exFAT |
| OS Compatibility |
Windows
macOS
Linux
Android
iOS
*As of November, 2022: Cheque with manufacturer for the most up-to-date compatibility |
| Mobile App Compatible |
No
*As of January, 2023: Cheque with manufacturer for the most up-to-date compatibility |
| Supported Browsers |
Chrome, Edge, Firefox, Safari |
| Supported Languages |
Brazilian Portuguese
Czech
Danish
Dutch
English
French
German
Hungarian
Italian
Japanese
Korean
Norwegian
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Thai
Traditional Chinese
Turkish |
| Security |
|
| Encryption |
AES-NI |
| Security Features |
Kensington Security Slot |
| VPN Server Connections |
40 |
| Electrical |
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Power Source |
AC Adapter |
| Power Consumption |
35.51 W (Typical)
11.52 W (Standby) |
| PSU Wattage |
1 x 100 W |
| Environmental |
|
| Operating Temperature |
32 to 104°F / 0 to 40°C |
| Operating Humidity |
8 to 80% |
| Operating Altitude |
16,404' / 5000 m |
| Storage Temperature |
-5 to 140°F / -20 to 60°C |
| Storage Humidity |
5 to 95% |
| Certifications |
FCC, COE, BSMI, VCCI, RCM, UKCA, EAC, CCC
*as per Manufacturer |
| Physical |
|
| Status Monitoring |
LED Indicator |
| Cooling |
2 x 92 mm Fan |
| Noise Level |
22.9 dBA |
| Built-In Speakers |
None |
| Dimensions |
8.78 x 7.83 x 6.54" / 223.01 x 198.88 x 166.12 mm |
| Weight |
4.9 lb / 2.2 kg |
