| Camera |
|
| Video System |
1080P60, 1080P50, 1080P30, 1080P25, 720P60, 720P50 |
| Sensor |
1/2.8-inch, CMOS, Effective Pixel: 2.07M |
| Scanning Mode |
Progressive |
| Lens |
12x, f=3.5mm ~ 42.3mm, F1.8 ~ F2.8 |
| Digital Zoom |
16x |
| Minimum Illumination |
0.5 Lux @ (F1.8, AGC ON) |
| Shutter |
1/30s ~ 1/10000s |
| White Balance |
Auto, Indoor, Outdoor, One Push, Manual, VAR |
| Backlight Compensation |
Support |
| Digital Noise Reduction |
2D&3D Digital Noise Reduction |
| SNR |
≥55dB |
| Horizontal FOV |
72.5° ~ 6.9° |
| Vertical FOV |
44.8° ~ 3.9° |
| Pan Angle |
±170° |
| Tilt Angle |
-25° ~ +30° |
| Pan Speed |
1.61° ~ 75.56°/s |
| Tilt Speed |
0.44° ~ 15°/s |
| Image Flip |
Support |
| Image Freeze |
Support |
| Preset Position |
255 |
| Preset Accuracy |
0.1° |
| MIC Pick-up Distance |
6m |
| USB Features |
|
| Operating System |
Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android |
| Color System/Compression |
MJPG/YUY2 |
| Video Format |
YUY2 (ISOC): 1080P@60fps (max.)
MJPEG: 1080P@60fps (max.) |
| USB Audio |
Supported |
| USB Video Communication Protocol |
UVC 1.1 |
| UVC PTZ |
Supported |
| Interfaces |
|
| USB Interface |
1 x USB3.0: Type-B |
| HDMI Interface |
1 x HDMI 1.4b |
| Audio Interface |
1 x LINE IN, 3.5mm |
| Communication Interface |
1 x RS232 IN: 8pin min DIN; Max. Distance: 30m; Protocol: VISCA/Pelco-D/Pelco-P
1 x RS232 OUT: 8pin min DIN; Max. Distance: 30m; Protocol: VISCA network use only |
| Power Jack |
JEITA type (DC IN 12V) |
| General Specifications |
|
| Input Voltage |
DC 12V |
| Input Current |
1.5A (max.) |
| Operating Temperature |
-10°C ~ 40°C |
| Storage Temperature |
-40°C ~ 60°C |
| Power Consumption |
12W (max.) |
| Dimension |
128mm x 118mm x 157.9mm |
| Net Weight |
1kg |
