Features
- 16 Voice Effects
- Compression, Reverb, Delay, and Enhance
- Adds up to 2 Voices for 3-Part Harmonies
- XLR Mic Input with 48V Phantom Power
- 3.5mm Stereo Aux Input
Related Products
Description
Make your vocal sound shine for your next livestream, home recording, or onstage performance with the Zoom V3 Vocal Processor, a vocal processor teeming with exciting effects and easy-to-use controls. You'll never have to enter a menu to access the V3's powerful functions thanks to the large, clearly-labelled knobs and illuminated buttons, letting your focus remain on being creative and entertaining.
Dedicated buttons provide instant switching of the 16 onboard effects, which range from chromatic or key-based pitch correction to a talk box, vocoder, beat box, and more. You can even add up to two voices to produce thick 3-part harmonies. Plus, compression, reverb, and delay are provided with their own separate controls for further refinement of your sound.
The V3 features a high-quality mic preamp with an XLR input, switchable 48V phantom power for condenser mics, and a special Enhance function that elevates vocal clarity. A 3.5mm stereo aux input ensures that you can easily play along with music from your smartphone or backing tracks from a computer. Stereo line and headphone outputs allow simultaneous hookup to a PA system and headphones, and the headphones' volume can be independently adjusted.
Additionally, the V3 offers USB audio interface functionality, should you want to record directly to your computer for creating podcasts, song demos, YouTube videos, or more. Run the V3 for up to 3.5 hours with AA batteries (not included), power it via USB, or connect the separately available Zoom AD-16 AC adapter for long-running projects.
Key Features:
Loaded with Effects
- Reverb, delay, and compression with dedicated control knobs
- Enhance function automatically optimises the performance of any mic for increased clarity
- Harmony function adds up to two voices to create 3-part harmonies in major and minor keys
- Formant Character button alters your vocal characteristics without changing the pitch
- Chromatic and key-based pitch correction
- Pitch-based effects including octave, unison, deep, robot, child, and chorus
- Special effects such as talk box, vocoder, beat box, whistle, distortion, and telephone
Flexible I/O
- XLR mic input with switchable 48V phantom power for condenser mics
- 3.5mm stereo aux input allows direct connection of a mobile device or computer for music playback
- 1/4" stereo line outputs for hookup to a PA system or mixer
- 3.5mm stereo headphone output with a dedicated volume control
- 1/4" control input supports separately available foot controllers such as the Zoom FS01 footswitch (for toggling effects on beat) or the Zoom FS02M expression pedal (for freely modulating effect parameters)
Compatible with Zoom SGV-6 Mic
- Works with the optional Zoom SGV-6 microphone
- SGV-6 aids in isolating your voice by suppressing ambient noise
USB Audio Interface
- Micro-USB port enables simple connectivity to your computer or mobile device for recording or streaming
- 2-input / 2-output USB 2.0 audio interface functionality
- Supports 44.1 kHz sample rate at 16-, 24-, or 32-bit
Versatile Placement
- Compact tabletop-friendly enclosure
- 1/4"-20 thread on rear panel for attachment to a mic stand using the separately available Zoom HRM-7 or HRM-11 mounts
Specifications
Effects | 16 (up to Five Concurrent Effects) |
Sample Rate | 44.1 kHz |
Bit Depth | Signal Processing: 32-Bit AD/DA Conversion: 24-Bit, 128x Oversampling |
Inputs | 1 x XLR 3-Pin Female Balanced Mic Input 1 x 1/8" / 3.5 mm TRS Female Unbalanced Stereo Aux Input |
Outputs | 2 x 1/4" TS Female Unbalanced Line Outputs 1 x 1/8" / 3.5 mm TRS Female Unbalanced Stereo Headphone Output |
Control Input | 1 x 1/4" TS (Compatible with Zoom FS01 and FP02M ) |
USB Port | 1 x Micro-USB 2.0 |
Audio Interface | 2-Input / 2-Output USB 2.0 Full Speed at 44.1 kHz / 16-, 24-, or 32-Bit |
Frequency Response | 20 Hz to 20 kHz (+1 dB / −3 dB, 10-Kilohm Load) |
Input Gain | Mic Input: +3 to +40 dB |
Input Level | Mic Input: +4 dBu (Maximum) Aux Input: -10 dBu (Rated) |
Output Level | Line Outputs: +6 dBu (Maximum) |
Headphone Output Power | 20 mW + 20 mW into 32-Ohm Load (Maximum) |
Input Impedance | Mic Input: 3 Kilohms or Greater (1 kHz) Aux Input: 22 Kilohms |
Output Impedance | Line Outputs: 100 Ohms |
Equivalent Input Noise | Mic Input: -125 dBu or Less (Phantom Power Off, A-Weighted, 150-Ohm Input, +40 dB Input Gain) |
Noise Floor | -75 dBu |
Phantom Power | +48 VDC |
Power Requirements | 4 x AA Batteries (not Included), 5 VDC via USB Bus Power, or 9 VDC via AC Power Adapter (Available Separately) |
Power Adapter | 9 VDC, 500 mA (Centre-Positive) via Zoom AD-16 AC Adapter (Available Separately) |
Battery Life | Up to 3.5 Hours |
Security | Kensington Lock Slot |
Mounting | 1 x 1/4"-20 Female Thread |
Dimensions (D x W x H) | 5.9 x 7.5 x 2" / 15 x 19 x 5 cm |
Weight | 1.3 lb / 0.6 kg (Excluding Batteries) |
In The Box
- Zoom V3 Vocal Processor
Reviews
(based on 1 rating)Give it a quick rating:
Thanks for your rating!
Write a review
-
Thomas
As a vocal processor, I love it it connects & supplies phantom power to my mic no problem & the effects are really diverse. But as an audio interface, it won't work at all because it won't connect to my computer no matter how many times I redownload the driver/firmware updates or change micro USB cords. I wouldn't have been able to use this thing at all since I got it if it weren't for the fact that I happened to have another separate interface for me to connect it to. It also won't charge through micro USB even though it's supposed to be able to :( thus I've had to buy rechargeable batteries & replace them every few hours which is getting pretty tiresome. Zooms customer service is atrocious, their emails back to me are just automated poorly translated gibberish.. but Rubber Monkey have a good reputation so hopefully I'll be able to get this issue sorted through them.Read more Read less
Details
- Product: Zoom V3 Vocal Processor
- Manufacturer: Zoom
- Model: V3
- SKU: V3
- RM Product #: 77604
