DPA d:screet Core 4061 Miniature Omnidirectional Microphone with MicroDot Connector (Lo-Sens, Beige)
Product #75747 | SKU 4061-OC-C-F00
In stock with supplier Usually ships in 2 - 3 working days
0.0 (no ratings yet) Thanks for your rating!


DPA d:screet Core 4061 Miniature Omnidirectional Microphone with MicroDot Connector (Lo-Sens, Beige)

Product #75747 | SKU 4061-OC-C-F00
In stock with supplier Usually ships in 2 - 3 working days


Product Features
  • For Stage and Television
  • Hardwired MicroDot Connector
  • Low Sensitivity, Loud SPL
  • Core Increases Mic Performance by 14 dB
  • Suitable for Wireless Transmitters
Customer Reviews
0.0 (no ratings yet) Thanks for your rating!
Email me when stock arrives
Product Details
  • Product: #75747
  • SKU: 4061-OC-C-F00
Our Price $739.00
- +
or 12 months interest free with
or 6 weekly payments from $123.16

Delivery - $6.90*
2 - 3 working days
Pickup AUCKLAND
2 - 3 working days
Pickup WELLINGTON
2 - 3 working days
*estimated shipping to Auckland

Related Products

Overview

The lo-sens, loud SPL, beige d:screet Core 4061 Miniature Omnidirectional Microphone with Hardwired MicroDot Connector from DPA is designed for use with wireless systems in performance and theatrical presentations. The Core 4061 miniature microphone amplifier delivers a 4 dB increase in dynamic range and a 14 dB decrease in THD (total harmonic distortion) over the 4061 Legacy model. Because of its small size, the microphone is highly unobtrusive and is suitable for broadcast, live stage, and instrument applications as well.

The d:screet Core 4061 includes interchangeable capsule protection grids that alter the sonic character of the microphone. A high-boost grid creates a peak at 12 kHz, bringing an airy texture to audio signals. The soft-boost grid creates a subtle boost between 8 to 20 kHz, enhancing signal presence.

With an SPL rating of 144 dB, the microphone is more than capable of reproducing transient (peaking) audio before clipping. The Core 4061 is powered via +48V phantom power and features a MicroDot output connector, compatible with various wireless microphone transmitters, or power supplies with standard XLR outputs.

Key Features:

  • Rugged and reliable
  • Natural audio quality
  • Low-noise
  • Large selection of accessories

Specifications

Microphone
Sound Field Mono
Operating Principle Pressure Operated
Capsule Condenser
Polar Pattern Omnidirectional
Performance
Frequency Range 20 Hz to 20 kHz
Maximum SPL 144 dB SPL Peak
Impedance 40 Ohms
Sensitivity 6 mV/Pa at 1 kHz
Dynamic Range 111 dB A-Weighted
Signal-to-Noise Ratio 68 dB A-Weighted
Equivalent Noise Level 38 dB ITU-R 468
THD < 1%
Connectivity
Output Connector Microdot
Cable Length 5.9' / 179.83 cm
Power
Operating Voltage 5 to 50 V
Physical
Operating Humidity 0 to 90%
Length 0.5" / 12.70 mm
Diameter 0.21" / 5.33 mm
Weight 0.26 oz / 7.5 g

In The Box

  • DPA Microphones d:screet Core 4061 Miniature Omnidirectional Microphone with MicroDot Connector (Lo-Sens, Beige)
  • High-Boost Protection Grid
  • Soft-Boost Protection Grid

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review
Details
  • Product: DPA d:screet Core 4061 Miniature Omnidirectional Microphone with MicroDot Connector (Lo-Sens, Beige)
  • Manufacturer: DPA Microphones
  • Model: 4061-OC-C-F00
  • SKU: 4061-OC-C-F00
  • RM Product #: 75747
  • Length Feet: 5.9 ft
