DPA d:screet Core 4061 Miniature Omnidirectional Microphone with MicroDot Connector (Lo-Sens, Beige)
Features
- For Stage and Television
- Hardwired MicroDot Connector
- Low Sensitivity, Loud SPL
- Core Increases Mic Performance by 14 dB
- Suitable for Wireless Transmitters
Related Products
Description
The lo-sens, loud SPL, beige d:screet Core 4061 Miniature Omnidirectional Microphone with Hardwired MicroDot Connector from DPA is designed for use with wireless systems in performance and theatrical presentations. The Core 4061 miniature microphone amplifier delivers a 4 dB increase in dynamic range and a 14 dB decrease in THD (total harmonic distortion) over the 4061 Legacy model. Because of its small size, the microphone is highly unobtrusive and is suitable for broadcast, live stage, and instrument applications as well.
The d:screet Core 4061 includes interchangeable capsule protection grids that alter the sonic character of the microphone. A high-boost grid creates a peak at 12 kHz, bringing an airy texture to audio signals. The soft-boost grid creates a subtle boost between 8 to 20 kHz, enhancing signal presence.
With an SPL rating of 144 dB, the microphone is more than capable of reproducing transient (peaking) audio before clipping. The Core 4061 is powered via +48V phantom power and features a MicroDot output connector, compatible with various wireless microphone transmitters, or power supplies with standard XLR outputs.
Key Features:
- Rugged and reliable
- Natural audio quality
- Low-noise
- Large selection of accessories
Specifications
| Microphone | |
| Sound Field | Mono |
| Operating Principle | Pressure Operated |
| Capsule | Condenser |
| Polar Pattern | Omnidirectional |
| Performance | |
| Frequency Range | 20 Hz to 20 kHz |
| Maximum SPL | 144 dB SPL Peak |
| Impedance | 40 Ohms |
| Sensitivity | 6 mV/Pa at 1 kHz |
| Dynamic Range | 111 dB A-Weighted |
| Signal-to-Noise Ratio | 68 dB A-Weighted |
| Equivalent Noise Level | 38 dB ITU-R 468 |
| THD | < 1% |
| Connectivity | |
| Output Connector | Microdot |
| Cable Length | 5.9' / 179.83 cm |
| Power | |
| Operating Voltage | 5 to 50 V |
| Physical | |
| Operating Humidity | 0 to 90% |
| Length | 0.5" / 12.70 mm |
| Diameter | 0.21" / 5.33 mm |
| Weight | 0.26 oz / 7.5 g |
In The Box
- DPA Microphones d:screet Core 4061 Miniature Omnidirectional Microphone with MicroDot Connector (Lo-Sens, Beige)
- High-Boost Protection Grid
- Soft-Boost Protection Grid
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: DPA d:screet Core 4061 Miniature Omnidirectional Microphone with MicroDot Connector (Lo-Sens, Beige)
- Manufacturer: DPA Microphones
- Model: Core 4061
- SKU: 4061-OC-C-F00
- RM Product #: 75747
- Length Feet: 5.9 ft
